Five Axis reciprocating spray painting sytem for car part

Short Description:


  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Port: Shenzhen
  • Payment Terms: L/C,D/A,D/P,T/T
  • Product Detail

    Product Tags

    Condition:
    New
    Type:
    Coating Production Line
    Substrate:
    Steel
    Coating:
    Painting
    Place of Origin:
    Guangdong, China (Mainland)
    Brand Name:
    FOD
    Model Number:
    F813AM005
    Voltage:
    220V
    Power(W):
    600W
    Dimension(L*W*H):
    (W)1500mmx(D)1200mmX(H)1800mm
    Weight:
    320KG
    Certification:
    CE ISO9001
    Warranty:
    1 Year
    After-sales Service Provided:
    Engineers available to service machinery overseas
    Used for:
    automatic UV &PU coating
    Machine clolor:
    Gray
    Dimention:
    (W)1500mmx(D)1200mmX(H)1800mm
    Input:
    220V,50HZ
    Output:
    600W
    Main material:
    50*50 square pipe steel and stainless steel
    Main control:
    PLC Touch Screen system
    Hs Code:
    8424899910
    Port:
    Shenzhen
    Use:
    Car auto parts painting, Photo frame painting, TV frame painting

    Packaging & Delivery

    Packaging Details
    Export standard package
    Delivery Time
    15days



     1. Five Axis reciprocating spray painting system Brief

    We specialized in manufacturing different type of axis automatic spray painting system covering single axis reciprocating spray painting system, X-Y axis spray painting system, Three, Four and Five axis spray painting system. The  technology is widely applied in various industries such as toy, electronics ,vacuum plating, wood door panel, automotive parts and plastic parts.



    2.   Five Axis reciprocating spray painting system Main advantage

    The axis spray painting system designed on basis of servo reciprocating and R,T and Z axis. It provides stable and balanced painting surface treatment, especially the spray fluid, atomization, angle and distance is very flexible adjusted as per the product,

    It can be easily operated by one worker and the spraying parameters can be fast saved in PLC memory card .Our axis spray painting equipment has been in hot popular since in market. It helps modern company saves much labor cost and increases production capacity.

    3. Five Axis reciprocating spray painting system Technical Parameter



    1,In put                                    220V,50HZ
    2,Output Power                                    600W
    3,Max Spraying Area                                   Max dia.50mm
    4,No. Spray Gun                                   1PCS
    5,Max No.of Work piece                                   4-120PCS
    6,Speed                                   (adjustable)
    7,Spay coating type                                 reciprocating 5 axis painting machine servo system
    8,Control Panel                                 PLC touch screen
    9,Dimensions(L*W*H)                                 1500mm*1200mm*1800mm
    10,Main Material                                 stainless  steel &steel
    11, X*Y*Z  travel area                                             850(X)*850(Y)*300(Z)
    12,Widely Application Laptop, display, LCD TV,Cellphone,MP3,Button,Desk computer Keyboard, Portable hard drive, Plastic ball, Car spare parts,  Photo Frame, Tablet computer pad









    4. Five Axis reciprocating spray painting system Picture Show

                                                               Infront View

















    5. Fast one-step Packing& delivery

    10 days disptach the machine since customer placed oder.







    6.  Installation service

      Engineer workers are available to make 20days installation and 5days testing production at customer’s factory  based on     final contract design drawing. Kindly note that for overseas installation,

    7.  Maintenance Warranty:

      One year warranty will be provided on the condition of normal operation of the machine. During the period of warranty, damaged    parts could be exchanged at free if the damaged is owing to bad quality of the goods, Damaged parts is required to return



    8. Contact us for the latest price of Five axis reciprocating spray painting system
