Manual powder coating plant for motorcycle

Short Description:

Condition: New Type: Coating Production Line Substrate: Aluminum Coating: Powder Coating Place of Origin: Chongqing, China (Mainland) Brand Name: FOD Voltage: 380~440V Power(W): Multi Power Dimension(L*W*H): Customized Size Weight: 4 TONS Certification: CE ISO9001 Warranty: 12 Months After-sales Service Provided: Engineers available to service machinery overseas Packaging & Delivery Packaging Details Film and Wooden case Delivery Time 25 Days 1.Manual powder...


  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Port: Shenzhen
  • Payment Terms: L/C,D/A,D/P,T/T
  • Product Detail

    Product Tags

    Condition:
    New
    Type:
    Coating Production Line
    Substrate:
    Aluminum
    Coating:
    Powder Coating
    Place of Origin:
    Chongqing, China (Mainland)
    Brand Name:
    FOD
    Voltage:
    380~440V
    Power(W):
    Multi Power
    Dimension(L*W*H):
    Customized Size
    Weight:
    4 TONS
    Certification:
    CE ISO9001
    Warranty:
    12 Months
    After-sales Service Provided:
    Engineers available to service machinery overseas

    Packaging & Delivery

    Packaging Details
    Film and Wooden case
    Delivery Time
    25 Days

    1.Manual powder coating plant for motorcycle Brief

    Powder coating line is a kind of environmental and economical surface treatment equipment to support a smooth and attractive durable coating effect. It is widely used in surface coating industry, especially applied for hardware products,Motorcycle, car wheels, bicycle bike and steel pipe. The main advantage of our powder coating line is environmental friendly and easy to operate and reclaim.

    The powder usage rate can achieve 98%,the coating thickness can be 100~300μm by once. Our equipment will surely help to make a better coating for our customers with support good quality ,save more production cost and increase qualified output .



    2.1.Manual powder coating plant for motorcycle Process and Parameter

    1,In put

          220V/380V/415V/440V,50HZ/60HZ

    2,Output Power

           5.5KW

    3,Overhead conveyor system

           UH2075HA chain, Speed 0-2.5m/min

    4,Max weight of each hanger

           Max 25kg/hanger

    5, Powder spray system

           Manual or Reciprocator spraying

    6,Powder spray booth

           With cyclone reclaim system, Reclaim rate 98%

    7,Powder curing oven

           With heating burner center+ Hot air circulation drying

    8,Oven temperature

    0-250 degree (adjustable)

    9, Control Panel

           PLC touch screen

    10,Powder spray gun

          WAGNER/KCI automatic electrostatic powder spray gun,

    12,Widely Application

    Automobile accessories, motor bike part, bicycle part, air conditional, steel pipe and other hardware metal powder coating



    2.1.Manual powder coating plant for motorcycle Picture Show









    5.Our Maintenance Guarantee

     One year warranty will be provided on the condition of normal operation of the machine. During the period of warranty, damaged parts could be exchanged at free if the damaged is owing to bad quality of the goods, Damaged parts is required to return us. If it was damaged by human being, parts will be exchanged or repaired at cost as quotation.

    Engineer is available to have installation,trainning serive for oversea customer.

    6.Fast Shipping Delivery

     1.Deliery within 10working days.

    2.FOB Shenzhen or CIF sea shipping.

    3.Wooden case package avoiding damage



    7.Contact us for the latest Price of Manual Powder Coating Plant
